Walkie Talkies

Hytera HP605

DMR Digital Portable Radio (No Display)

Contact for Price

Minimum Order Quantity:10 units

The Hytera HP605 is a compact and lightweight DMR digital portable radio from the HP6 series (HP60X variant without keypad), designed for customer-facing staff who need reliable communication with professional clarity. Small and light in style at only 265g weight and 30.5mm thickness, it delivers uncompromising clear audio and extended coverage together with powerful battery, exceptional ruggedness and abundant features. The integrated BT5.0 technology provides flexible wireless connection with accessories to keep hands free, while GNSS location services enable real-time tracking and dispatch capabilities. With 1024 channel capacity and dual-mode analog/digital operation, the HP605 ensures seamless communication for hospitality, retail, healthcare, and service industries.

IP67 Waterproof

MIL-STD-810G

ETSI DMR Compliant

Bluetooth 5.0

GNSS (GPS/GLONASS/BDS)

AES128/AES256 Encryption

Download Datasheet (PDF)

Key Features

Light & Stylish

Streamlined compact design at only 265g weight and 30.5mm thickness for easy carrying and wearing. Professional appearance suitable for customer-facing staff in hospitality and service industries.

Long Battery Life

Proprietary technologies reduce power consumption. 2000mAh Li-polymer battery delivers over 20 hours@5-5-90 standard duty cycle (GNSS OFF), 16 hours with GNSS ON.

Rugged & Durable

IP67 rated and MIL-STD-810G compliant, resilient to 2-meter drop. Built to withstand tough environments without slowing your staff down.

Crystal Clear Audio

Optimized powerful loudspeaker for clear sound in noisy environments. Water-porting technology drains water from speaker cavity. AI-based noise cancellation decreases 30dB background noise.

Easy to Use

Tactile PTT and programmable buttons. 0.91-inch OLED display. BT5.0 enables wireless accessory connectivity. Simple menu navigation for quick access to functions.

Extended Coverage

Improved receiver sensitivity provides better connectivity in marginal areas and indoors. Enhanced safety and operational benefits for field operatives.

Technical Specifications

Frequency RangeUHF: 400-527 MHz / VHF: 136-174 MHz

Channel Capacity1024 channels

Zone Capacity64 zones

Zone Channels256 channels per zone

Channel Spacing12.5 kHz / 20 kHz / 25 kHz

Operating Voltage7.7V (rated)

Battery2000 mAh Li-polymer

Battery Life (5/5/90)20h (GNSS OFF) / 16h (GNSS ON)

Frequency Stability±0.5 ppm

Antenna Impedance50Ω

Dimensions (HP60X)122 x 55 x 30.5 mm

Weight (HP60X)265g (with antenna & battery)

Display0.91 inch OLED Display

BluetoothBT 5.0 BLE+EDR

Receiver Sensitivity (Analog)0.16 μV typical (12 dB SINAD)

Receiver Sensitivity (Digital)0.18 μV (BER 5%)

Adjacent Channel Selectivity60dB @ 12.5kHz / 70dB @ 20/25kHz

Intermodulation70dB @ 12.5/20/25kHz (TIA-603)

Spurious Response Rejection70dB @ 12.5/20/25kHz

Blocking80dB (TIA-603) / 84dB (ETSI)

Rated Audio Power Output0.5W

Rated Audio Distortion≤3%

RF Power OutputUHF: 1W/4W, VHF: 1W/5W

FM Modulation11KOF3E@12.5kHz, 14KOF3E@20kHz, 16KOF3E@25kHz

4FSK Digital Modulation7K60FXD (Data Only), 7K60FXW (Data & Voice)

Digital Vocoder TypeAMBE+2

Digital ProtocolETSI TS 102 361-1, -2, -3

Operating Temperature-30°C* to +60°C (*Radio only, Battery -20°C)

Storage Temperature-40°C to +85°C

ESD Protection±8kV (contact) / ±15kV (air)

Dustproof & WaterproofIEC 60529 - IP67

HumidityPer MIL-STD-810G Standard

Shock and VibrationPer MIL-STD-810G Standard

GNSSGPS, GPS+GLONASS, GPS+BDS

TTFF Cold Start<1 minute

TTFF Hot Start<10 seconds

Horizontal Accuracy<5 meters (95th percentile, >5 satellites visible)
