Motorola APX 6000

APX P25 Single-Band Portable Radio

Contact for Price

Minimum Order Quantity:1 unit

The Motorola APX 6000 is a P25 single-band portable radio delivering mission-critical wireless communications with advanced Wi-Fi connectivity, Bluetooth 4.0 LE encryption, and superior audio intelligence. With IP68 waterproof rating (2m/4hrs), MIL-STD-810 C/D/E/F/G certified durability, and FIPS 140-3 Level 3 encryption, the APX 6000 ensures secure, reliable communications for public safety, emergency services, and industrial users in the most demanding environments.

IP68 Waterproof (2m/4hrs)

MIL-STD-810 C/D/E/F/G Certified

FIPS 140-3 Level 3

FIPS 197 Compliant

FCC Certified (AZ489FT4892)

IC Certified (MNUE1038A)

P25 CAI Compliant

ASTRO 25 Compatible

Download Datasheet (PDF)

Key Features

Mission Critical Wireless

Wi-Fi 802.11 b/g/n with SmartConnect automatic channel switching maintains voice continuity. Bluetooth 4.0 LE with 128-bit AES-CCM encryption provides secure earpiece connectivity. Seamless roaming between coverage areas.

Superior Audio Intelligence

Adaptive Audio Engine automatically adjusts volume and audio profiles based on environment. 3W high-power speaker delivers exceptional audio clarity. Three-microphone noise cancellation filters background noise from sirens, engines, and heavy equipment.

Advanced Security & Encryption

256-bit AES encryption with FIPS 140-3 Level 3 certification. ADP standard, DES-XL, DES-OFB, DVP-XL optional. Mission Critical Wireless Bluetooth provides encrypted link to high-performance earpieces. Tamper-protected key storage.

Precision GPS Tracking

Integrated GPS/GLONASS receiver with <5 meter accuracy. Real-time location tracking for personnel safety and resource management. Geofencing capabilities with automatic alerts. 12-channel receiver with -159 dBm sensitivity.

Rugged & Waterproof Design

IP68 rated (submersible 2m/4hrs) exceeds industry standards. MIL-STD-810 C/D/E/F/G certified for extreme shock, vibration, temperature (-30°C to +60°C). Rugged housing withstands drops, dust, salt fog, and harsh conditions.

Enhanced User Experience

Full color LCD display with intelligent lighting notifications. Backlit keypad with 3 soft keys and 4-way navigation. 16-position rotary channel selector with orange emergency button. Radio profiles for quick customization.

Technical Specifications

Product SeriesMotorola APX 6000 P25 Portable Radio

Model NumberH98QDH9PW7AN (UHF R1)

FCC IDAZ489FT4892

IC ModelMNUE1038A

Frequency RangeVHF: 136-174 MHz | UHF R1: 380-470 MHz | UHF R2: 450-520 MHz | 700/800 MHz: 763-870 MHz

Operating ModeP25 Phase 1 FDMA / Phase 2 TDMA

Channel Capacity1000 channels (Model 3.5)

Channel Spacing25/12.5 kHz (analog) | 12.5 kHz (digital)

RF Output Power (VHF)1-5W (adjustable)

RF Output Power (UHF R1/R2)1-5W (adjustable)

RF Output Power (700/800 MHz)1-3W (adjustable)

Modulation TypeC4FM (digital), 4FSK, 16K0F3E (analog)

Digital ProtocolAPCO P25 Phase 1 FDMA / Phase 2 TDMA, 9600 Baud

Analog ConventionalSmartNet, SmartZone, Omnilink, MDC 1200, Quik Call II

Digital ConventionalAPCO P25, ASTRO 25

Frequency Stability (-30°C to +60°C)±0.00010%

Emissions (Conducted)<-75 dB

Audio Response+1, -3 dB (EIA)

FM Hum & Noise-45 to -53 dB

Audio Distortion≤3% @ 12.5/25 kHz

Receiver Sensitivity (Analog)0.188-0.250 μV (12 dB SINAD)

Receiver Sensitivity (Digital)0.188-0.250 μV (5% BER)

Selectivity-67 to -76 dB

Intermodulation-75 to -79 dB

Spurious Rejection-76.6 to -80.5 dB

Audio Output Power3W rated

Display TypeFull dot matrix color LCD (Model 2.5/3.5)

Display Features4 lines of text x 14 characters | White backlight | Intelligent lighting notifications

KeypadBacklight keypad | 3 soft keys | 4 direction navigation key | Home and Data buttons

Encryption Algorithms256-bit AES / ADP / DES / DES-XL / DES-OFB / DVP-XL

Encryption Capacity8 algorithms

Encryption Keys per RadioModule capable of storing 1024 keys (48 CKR or 16 PID)

Encryption StandardsFIPS 140-3 Level 3, FIPS 197

Key StorageTamper protected volatile or non-volatile memory

Key ErasureKeyboard command and tamper detection

GPS Channels12 channels (GPS/GLONASS)

GPS Tracking Sensitivity-159 dBm

GPS Accuracy<5 meters (95%)

GPS Cold Start<60 seconds (95%)

GPS Hot Start<10 seconds (95%)

GPS ModeAutonomous (Non-Assisted) GPS

Wi-Fi Standard802.11 b/g/n

Wi-Fi FeatureSmartConnect automatic channel switching

BluetoothMission Critical Wireless 4.0 LE

Bluetooth Encryption128-bit AES-CCM

Battery Type (Standard)Li-Ion IMPRES 2 2550 mAh IP68 (PMNN4485)

Battery Options1500 mAh | 2200 mAh | 2550 mAh IP68 | 3000 mAh extended

Battery Life (5-5-90 Duty Cycle)18-24 hours digital (typical)

Dimensions (Radio without Battery)139 x 60.7 x 35.6 mm (5.47 x 2.39 x 1.40 in)

Weight (Radio without Battery)309g (10.9 oz)

Operating Temperature-30°C to +60°C

Storage Temperature-40°C to +85°C

Water & Dust ProtectionIP68 (submersible 2m/4hrs)

Military StandardMIL-STD-810 C/D/E/F/G (Low Pressure, High/Low Temperature, Temperature Shock, Solar Radiation, Rain, Humidity, Salt Fog, Blowing Dust/Sand, Vibration, Shock)

FLASHport Memory64 MB

Programming SoftwareWindows Customer Programming Software (CPS)

Radio ProfilesMultiple configurable profiles

Unified Call ListSupported

Text MessagingSupported (optional)

Man Down/Fall AlertSupported (optional)

Site Selectable Alert TonesSupported (optional)

P25 Link Layer AuthenticationSupported (optional)

Enhanced DataSupported (optional)

Programming Over Project 25Supported (optional)

OTAR/OTAPSupported (optional)

Mission Critical GeofencingSupported (optional)

P25 CertificationCompliant

Warranty1 year manufacturer warranty
