Motorola R7 FKP

MOTOTRBO R7 Full Keypad Portable Radio

Contact for Price

Minimum Order Quantity:10 units

The MOTOTRBO R7 Full Keypad (FKP) is a premium portable two-way radio featuring advanced digital technology with full keypad interface for comprehensive control. With 1000 channel capacity, IP68/IP66 protection, and MIL-STD-810H compliance, the R7 FKP delivers exceptional performance in the most demanding environments. The 2.4-inch QVGA color display provides clear information visibility, while AI-powered noise cancellation and IMPRES Audio technologies ensure intelligible communication in extreme noise conditions. Integrated Wi-Fi 2.4/5.0 GHz with WPA3 security, Bluetooth 5.2, and GNSS location tracking enable seamless connectivity and asset management.

IP68 Rated (2m/2hrs)

IP66 Rated (water jet)

MIL-STD-810 C/D/E/F/G/H

TIA4950 Hazloc Certified

ETSI DMR Tier II/III Compliant

FCC Certified

IC Certified

Maritime Certified (VHF models)

WPA3 Wi-Fi Security

Bluetooth 5.2 Certified

Download Datasheet (PDF)

Key Features

Advanced Digital Technology

TDMA dual-slot technology doubles channel capacity within 12.5 kHz bandwidth. 1000 channel capacity across multiple zones supports large-scale deployment. DMR Tier II and Tier III compliant with backward analog compatibility.

Superior Audio Quality

AI-trained noise suppression and adaptive dual microphone noise cancellation filter background interference. Automatic acoustic feedback suppression eliminates whistling. Programmable loudness up to 107 phons ensures intelligible communication in extreme noise.

Rugged Construction

IP68 rated for submersion up to 2 meters for 2 hours. IP66 rated for concentrated water jet pressure. Built to MIL-STD-810H standards for shock, vibration, and extreme temperature resistance from -30°C to +60°C.

Extended Battery Life

Multiple battery options: 2200mAh (20hrs digital), 2850mAh (26hrs digital), or 3200mAh (29hrs digital). IMPRES smart battery management optimizes charging cycles and extends battery lifespan.

Full Keypad Interface

Complete alphanumeric keypad enables direct frequency entry, text messaging, and menu navigation. 2.4-inch QVGA display (320x240 pixels) with up to 10 lines of text for comprehensive information display.

Advanced Connectivity

Integrated Wi-Fi 2.4/5.0 GHz with WPA3 security protocol. Bluetooth 5.2 supports audio and data profiles. GNSS support for GPS, GLONASS, BEIDOU, and GALILEO constellations with <5m accuracy.

Technical Specifications

Product SeriesMOTOTRBO R7 Series Portable Radios

ModelR7 FKP - Full Keypad Model

Frequency RangeVHF: 136-174 MHz / UHF: 400-527 MHz / 800/900 MHz

Channel Capacity1000 channels (FKP variant)

Channel Spacing12.5 / 20.0 / 25.0 kHz

Operating Voltage7.5V DC (nominal)

Battery Options2200mAh / 2850mAh / 3200mAh Li-ion IP68

Battery Life (2200mAh, Digital)20 hours (5/5/90 duty cycle)

Battery Life (2200mAh, Analog)15 hours (5/5/90 duty cycle)

Battery Life (2850mAh, Digital)26 hours (5/5/90 duty cycle)

Battery Life (2850mAh, Analog)19.5 hours (5/5/90 duty cycle)

Battery Life (3200mAh, Digital)29 hours (5/5/90 duty cycle)

Battery Life (3200mAh, Analog)22 hours (5/5/90 duty cycle)

Dimensions (2200mAh)131.8 x 56 x 34.7 mm (5.2 x 2.2 x 1.4 in.)

Dimensions (2850mAh)131.8 x 56 x 34.7 mm (5.2 x 2.2 x 1.4 in.)

Dimensions (3200mAh)131.8 x 56 x 37.3 mm (5.2 x 2.2 x 1.5 in.)

Weight (2200mAh)316g (11 oz) with antenna and battery

Weight (2850mAh)333g (12 oz) with antenna and battery

Weight (3200mAh)366g (13 oz) with antenna and battery

Display2.4-inch QVGA color display (320 x 240 pixels)

Display LinesUp to 10 lines of text

Programmable Buttons6 programmable buttons (FKP variant)

Protection RatingIP68 (2m submersion, 2hrs) / IP66 (water jet)

Military StandardMIL-STD-810 C/D/E/F/G/H

Operating Temperature-30°C to +60°C (-22°F to +140°F)

Storage Temperature-40°C to +85°C (-40°F to +185°F)

Frequency Stability±0.5 ppm

Antenna Impedance50Ω

RF Power Output (VHF High)5W

RF Power Output (VHF Low)1W

RF Power Output (UHF High)4W

RF Power Output (UHF Low)1W

RF Power Output (800/900 High)2.5W

RF Power Output (800/900 Low)1W

Modulation (Analog 12.5kHz)11K0F3E

Modulation (Analog 25kHz)16K0F3E

Modulation (Digital 12.5kHz Data)7K60F1D / 7K60FXD

Modulation (Digital 12.5kHz Voice)7K60F1E / 7K60FXE

Digital ProtocolETSI TS 102 361-1/-2/-3/-4 DMR Tier II and Tier III

Digital VocoderAMBE+2

Conducted Spurious Emission<-36 dBm (<1GHz) / <-30 dBm (>1GHz)

Adjacent Channel Power (Tx)>60 dB @ 12.5 kHz / >70 dB @ 20/25 kHz

FM Hum and Noise (Tx)-40 dB @ 12.5 kHz / -45 dB @ 20/25 kHz

Audio Response (Tx)+1 to -3 dB

Audio Distortion (Tx)≤1.5%

Receiver Sensitivity (Analog)0.16 μV typical (12 dB SINAD)

Receiver Sensitivity (Digital)0.14 μV typical (5% BER)

Adjacent Channel Selectivity (Rx)>60 dB @ 12.5 kHz / >70 dB @ 20/25 kHz

Intermodulation (Rx)>70 dB

Spurious Rejection (Rx)>70 dB

Audio Output Power (Rated)1W

Audio Output Power (Max)3W

Maximum Speech Loudness102 phon default / 107 phon programmable @ 30 cm

Wi-Fi StandardsWi-Fi 5 / IEEE 802.11a/b/g/n/ac

Wi-Fi Frequency2.4 GHz / 5.0 GHz

Wi-Fi SecurityWPA-3, WPA-2

Bluetooth VersionBluetooth Core 5.2 (Dual Mode)

Bluetooth RangeClass 2, 10m (33 ft)

GNSS ConstellationsGPS, GLONASS, BEIDOU, GALILEO

GNSS Accuracy<5 meters horizontal

Time To First Fix (Cold)≤60 seconds

Time To First Fix (Hot)≤10 seconds

FCC IDAZ489FT7144 (VHF) / AZ489FT7143 (UHF) / AZ489FT7169 (800/900)

IC ID109U-89FT7144 (VHF) / 109U-89FT7143 (UHF) / 109U-89FT7169 (800/900)
