Walkie Talkies

Motorola R2

MOTOTRBO Portable Two-Way Radio

Contact for Price

Minimum Order Quantity:10 units

The MOTOTRBO R2 is an everyday workhorse portable two-way radio that marries durability and ergonomics to ensure confident, easy handling. With long range, configurable audio and seamless integration, the R2 delivers reliable performance for uninterrupted workday communication. Featuring a sleek and ergonomic form factor, IP55 dust and water ingress protection, and MIL-STD 810 ruggedness, the R2 supports 64 channels with dual-slot TDMA technology for spectrum-efficient digital communication.

IP55 Rated

MIL-STD 810 C/D/E/F/G/H

ETSI DMR Tier II Compliant

FCC Certified

IC Certified

Secure Enhanced Linux OS

Download Datasheet (PDF)

Key Features

Ergonomic Design

Sleek and ergonomic form factor ensures comfortable all-day handling. Intuitive button layout and channel selector provide easy one-handed operation. Compact dimensions (4.9 x 2.2 x 1.3 in) fit naturally in hand for extended use without fatigue.

Extended Battery Life

2100mAh IP55 battery delivers 17 hours analog / 22.5 hours digital operation. Optional 2300mAh high-capacity battery extends usage to 19.5 hours analog / 26.5 hours digital. Smart battery management ensures reliable all-day performance.

Superior Audio Quality

User-selectable audio profiles optimize voice clarity for different environments. SINC+ noise suppression filters background interference. Received audio leveling maintains consistent volume. Loudness up to 101 phons ensures intelligible communication in noisy conditions.

Rugged Construction

IP55 rated protection against dust and water ingress. Built to MIL-STD 810 C/D/E/F/G/H standards for shock, vibration, and extreme temperature resistance. Operating temperature from -30°C to +60°C ensures reliable performance in harsh environments.

Digital Efficiency

TDMA dual-slot technology doubles channel capacity within 12.5 kHz bandwidth. DMR Tier II compliant with backward analog compatibility. 64 channel capacity supports scalable deployment for growing organizations.

Advanced Features

Dual Capacity Direct Mode for enhanced coverage. Transmit interrupt for priority communications. Voice announcement and home channel reminder for intuitive operation. 2 programmable buttons enable quick access to frequently used functions.

Technical Specifications

Product SeriesMOTOTRBO R2 Portable Two-Way Radio

ModelR2 (Motorola Solutions)

Frequency RangeVHF: 136-174 MHz / UHF: 400-480 MHz

Channel Capacity64 channels

Channel Spacing12.5 / 25.0 kHz

Operating Voltage7.5V DC (nominal)

Battery Type (Standard)2100mAh Li-ion IP55 (PMNN4600)

Battery Type (Optional)2300mAh Li-ion IP55 (PMNN4598)

Battery Life (2100mAh, Analog)17 hours (5/5/90 duty cycle)

Battery Life (2100mAh, Digital)22.5 hours (5/5/90 duty cycle)

Battery Life (2300mAh, Analog)19.5 hours (5/5/90 duty cycle)

Battery Life (2300mAh, Digital)26.5 hours (5/5/90 duty cycle)

Dimensions (2100mAh)4.9 x 2.2 x 1.3 in (124 x 56 x 33 mm)

Dimensions (2300mAh)4.9 x 2.2 x 1.5 in (124 x 56 x 38 mm)

Weight (2100mAh)9.2 oz (261g) without antenna

Weight (2300mAh)10.1 oz (286g) without antenna

DisplayNone (standard model)

Programmable Buttons2 programmable buttons

Protection RatingIP55 (dust and water ingress protection)

Military StandardMIL-STD 810 C/D/E/F/G/H

Operating Temperature-30°C to +60°C (-22°F to +140°F)

Storage Temperature-40°C to +85°C (-40°F to +185°F)

Frequency Stability±0.5 ppm

Antenna Impedance50Ω

RF Power Output (VHF High)5W

RF Power Output (VHF Low)1W

RF Power Output (UHF High)4W

RF Power Output (UHF Low)1W

Modulation (Analog 12.5kHz)11K0F3E

Modulation (Analog 25kHz)16K0F3E

Modulation (Digital 12.5kHz Data)7K60F1D / 7K60FXD

Modulation (Digital 12.5kHz Voice)7K60F1E / 7K60FXE

Digital ProtocolETSI TS 102 361-1/-2/-3 DMR Tier II

Digital VocoderAMBE+2

Conducted Spurious Emission<-36 dBm (<1GHz) / <-30 dBm (>1GHz)

Adjacent Channel Power (Tx)>60 dB @ 12.5 kHz / >70 dB @ 25 kHz

FM Hum and Noise (Tx)-40 dB @ 12.5 kHz / -45 dB @ 25 kHz

Audio Response (Tx)+1 to -3 dB

Audio Distortion (Tx)3% typical

Receiver Sensitivity (Analog)0.18 μV typical (12 dB SINAD)

Receiver Sensitivity (Digital)0.16 μV typical (5% BER)

Adjacent Channel Selectivity (Rx)>60 dB @ 12.5 kHz / >70 dB @ 25 kHz

Intermodulation (Rx)>70 dB

Spurious Rejection (Rx)>70 dB

Audio Output Power (Rated)1W

Audio Output Power (Max)3W

Maximum Speech Loudness101 phons (ISO 532B)

FCC IDAZ489FT3852 (VHF) / AZ489FT4971 (UHF)

IC ID89FT3852 (VHF) / 109U-89FT4971 (UHF)
