Motorola DP1400
Walkie Talkies

Motorola DP1400

Analog Two-Way Radio

Contact for Price
Minimum Order Quantity:10 units

The Motorola DP1400 is a reliable analog two-way radio designed for essential voice communications in commercial and industrial environments. With its compact and lightweight design, the DP1400 delivers clear audio quality and dependable performance for teams requiring straightforward, cost-effective communication solutions. Featuring 16 channel capacity, VOX hands-free operation, and extended battery life, this radio is ideal for hospitality, retail, manufacturing, and security applications where simple, reliable communication is paramount.

IP54 Rated
MIL-STD-810 C/D/E/F/G Tested
FCC Part 90
IC RSS-119
CE Certified
RoHS Compliant

Key Features

Clear Audio Quality

Advanced audio processing delivers clear voice transmission even in noisy environments. Powerful speaker output ensures messages are heard clearly across your workplace.

Compact & Lightweight

Ergonomic design fits comfortably in hand for extended use. Lightweight construction reduces operator fatigue during long shifts. Intuitive button layout enables easy operation.

VOX Hands-Free

Voice-operated transmission enables hands-free operation with compatible headsets. Ideal for situations requiring both hands for tasks while maintaining communication.

Long Battery Life

Extended battery capacity supports full shift operations. Low power consumption reduces operating costs and ensures reliable all-day communication.

Durable Design

Built to withstand daily commercial use with robust housing. Tested to military standards for reliability in demanding work environments.

Technical Specifications

Frequency RangeVHF: 136-174 MHz / UHF: 400-470 MHz
Channel Capacity16 channels
Channel Spacing12.5 kHz / 20 kHz / 25 kHz
Operating Voltage7.4V (nominal)
Battery TypeLi-Ion 1500mAh (standard)
Battery Life (Analog)Approx. 14 hours (5/5/90 duty cycle)
DisplayNone (basic analog model)
KeypadNo keypad
Protection RatingIP54 (dust and water spray resistant)
Military StandardMIL-STD-810 C/D/E/F/G tested
BluetoothNot available
Wi-FiNot available
GNSSNot available
Audio Output0.5W nominal
ModulationFM Analog, 11K0F3E @ 12.5kHz
Receiver Sensitivity (Analog)0.25 μV typical (12dB SINAD)
Adjacent Channel Selectivity60dB @ 12.5kHz / 70dB @ 25kHz
RF Power Output4W (UHF) / 5W (VHF)
Dimensions (H x W x D)118 x 54 x 35 mm (without antenna)
Weight245g (with antenna and battery)
Operating Temperature-20°C to +60°C (-4°F to +140°F)
Storage Temperature-40°C to +85°C (-40°F to +185°F)
Frequency Stability±0.5 ppm
Antenna Impedance50Ω
VOX SupportYes (with compatible accessories)
Emergency ButtonOptional (programmable)
