Walkie Talkies

Hytera HP785

DMR Digital Portable Radio

Contact for Price

Minimum Order Quantity:10 units

The Hytera HP785 is a next-generation DMR digital portable radio that sets new standards in quality and performance. Featuring a large 2.4-inch HD TFT-LCD display with 240x300 resolution and 262,000 colors, it delivers exceptional clarity even in direct sunlight. The radio incorporates advanced AI-based voice enhancement with deep learning technology that accurately extracts voice from noise, reducing unwanted background sounds by up to 30dB. With IP68 waterproof rating and MIL-STD-810 G durability, the HP785 is built for the most demanding environments while maintaining a slim profile of just 29.5mm thickness and weighing less than 310g.

IP68 Waterproof (2m for 4hrs)

MIL-STD-810 C/D/E/F/G

ETSI DMR Compliant

Bluetooth 5.0

GPS (Optional)

AES128/AES256 Encryption

Download Datasheet (PDF)

Key Features

Louder & Clearer Audio

Industry-leading 36mm forward-facing speaker delivers up to 93dB loudness. AI-based voice enhancement with deep learning reduces background noise by 30dB. Water-porting technology quickly drains water from speaker cavity.

Thinner & Lighter

Optimized mechanical design with advanced materials and 4.3mm speaker achieves compact 29.5mm thickness. Lightweight lithium polymer battery keeps weight under 11 ounces (310g) for all-day comfort.

Higher Ruggedness

Fully compliant with IP68 (submersible 2m for 4hrs) and MIL-STD-810 G (2m drop tested). Anti-magnetic speaker prevents attraction of metal dust and shavings in industrial environments.

Enhanced Safety

Easy-access emergency button with one-touch help summon. Lone Worker prompts periodic check-ins. Man Down automatically enters emergency mode when radio remains motionless or inclined at preset angle. Optional GPS provides real-time location tracking.

Long Battery Life

Advanced lithium polymer 2400mAh battery delivers up to 24 hours on high transmit power with 5/5/90 duty cycle. Smart energy management extends operational time for three-shift operations.

Smart Connectivity

Bluetooth 5.0 BLE+EDR enables wireless accessory connectivity. MicroSD card slot supports voice recording and additional storage. Multi-system operation supports analog, digital, MPT/XPT trunking, and DMR Tier II/III systems.

Technical Specifications

Frequency RangeUHF: 350-470 MHz / VHF: 136-174 MHz

Channel Capacity1,024 channels (512 analog, 512 digital)

Zone Capacity64 zones with 256 channels per zone

Channel Spacing12.5 kHz / 20 kHz / 25 kHz

Operating Voltage7.7V (rated)

Battery Type2400mAh Li-ion Polymer

Battery Life (5/5/90 Duty Cycle)UHF: 24hrs / VHF: 21hrs (GPS disabled: 26hrs/25hrs)

Display2.4" TFT-LCD, 320x240 pixels, 262,000 colors, 10 rows

Protection RatingIP68 (submersible 2m for 4hrs)

Military StandardMIL-STD-810 C/D/E/F/G (2m drop tested)

BluetoothVersion 5.0 BLE+EDR

GPS Accuracy<5 meters horizontal, TTFF cold <60s, hot <10s

Dimensions (H x W x D)132 x 55 x 29.5 mm (without antenna)

Weight310g (with antenna and battery)

Operating Temperature-20°C to +60°C (-0°F to +140°F)

Storage Temperature-40°C to +85°C (-40°F to +185°F)

HumidityPer MIL-STD-810 C/D/E/F/G standard

ESD ProtectionIEC 61000-4-2 Level 4: ±8kV contact, ±15kV air

RF Power OutputVHF: 1-5W / UHF: 1-4W (adjustable)

Modulation4FSK digital (12.5kHz), AMBE+2 vocoder

Digital ProtocolETSI TS 102 361-1/2/3 DMR Tier II & III

Receiver Sensitivity (Digital)0.18 μV (BER 5%)

Receiver Sensitivity (Analog)0.16 μV typical (12dB SINAD)

Adjacent Channel Selectivity60dB @ 12.5kHz / 70dB @ 20/25kHz

Audio Output Power0.5W nominal, ≤3% distortion

Frequency Stability±0.5 ppm

Antenna Impedance50Ω
